WANLUTECH 8K IP Camera Tester, 90W PoE Power Out 8MP SDI TVI CVI AHD CVBS Camera Test SFP Test TDR Cable Tester Digital Multimeter OPM VFL WiFi Network Tools HDMI VGA in(H12-MOVTADHSEF)
WANLUTECH 8K IP Camera Tester, 90W PoE Power Out 8MP SDI TVI CVI AHD CVBS Camera Test SFP Test TDR Cable Tester Digital Multimeter OPM VFL WiFi Network Tools HDMI VGA in(H12-MOVTADHSEF)
Regular price
$669.99 USD
Regular price
$712.29 USD
Sale price
$669.99 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Model | H12-MOVTADHSEF |
| Display | 8 inch IPS touch screen, Full-view capacitive touch screen,1920x1200 resolution |
| Network interface | Dual Gigabit Ethernet ports, 10/100/1000M adaptive interface |
| WIFI Speed | 150M/433M WIFI Speed,supporting frequency band 2.4/5G |
| WiFi analyzer/WIFI hotspot | Analyze Wi-Fi networks, test signal strength, and evaluate channel occupancy and ratings with the built-in Wi-Fi analyzer. |
| SFP module slot | Single，Features one SFP fiber optic interface, compatible with Gigabit SFP modules for fiber optic network testing. |
| IP camera test | Support max 8K 32MP IP camera test, Support ONVIF protocol,H.265 decoding:h.265-8K/24FPS h.264-4K/30FPS |
| IP Discovery/Quick ONVIF/IP Camera Test /RTSP play /Client APK | |
| Upgraded version of UltraFast ONVIF,Hik One-Click Activation (Legacy Cameras), ONVIF Report Generation, Cross-Subnet Testing, ONVIF Audio Test, WDR Test, Modify Channel Name, Face Recognition. | |
| Rapid Video: Auto view the video, create testing report | |
| Hik test tool: Batch Activation & IP Modification, Auto-Enable ONVIF, Set Encoding Format & Resolution, Rename Channels, Reset Password, Video Masking. | |
| DH Testing Tool: Batch Activation & IP Modification, Reset Phone Number Reservation, Channel Renaming, Video Masking. |
|
| Network test | IP discovery, Link monitor, DHCP server, port flashing, Ping test |
| Coaxial camera test | TVI 5.0 camera test, 3840 x 2160P 15 FPS, 4xzoom support coaxial audio, UTC control & call OSD menu |
| 8MP CVI test, 3840 x 2160P 12.5/15 FPS, 4xzoom,support UTC control & call OSD menu | |
| 8MP AHD test, 3840 x 2160P 15 FPS,4xzoom，support UTC control & call OSD menu | |
| Video transmission quality test/Image picture quality test/Lens simulation/camera focus :ONVIF/TVI/CVI/ AHD/SDI | |
| 8MP EX-SDI test, 3840 x 2160P 25/30 FPS,4xzoom, support UTC control & call OSD menu | |
| HD-SDI test, 1920 x 1080P 25/30/50/60 FPS, 4xzoom | |
| 3G-SDI test, 1920 x 1080P 50/60 FPS, 4xzoom | |
| Coaxial test | BNC input & BNC looped output, PAL/NTSC Video Signal Test,Cloud paltform RS485 control,Simulation video test,Video screenshots, videos, playback |
| Analog video level meter, peak video signal level, SYNC signal level, | |
| Max 4K 3840x2160 15FPS HD CVI TVI AHD color bar test, CVBS PAL/NTSC color bar test,4K color bar output,BNC Cable Loopback Test | |
| HDMI input/output& VGA input | HDMI input 4K 3840x2160P 30FPS |
| HDMI output, 4K 3840x2160P 60FPS | |
| VGA input,Up to 1920*1200 60FPS | |
| Power output | PoE++ power output,55V PoE power output, max power 90W |
| DC power output:DC24V 2A, DC12V 3A power output | |
| USB power output:DC5V 2A power output, can connect USB camera, USB and Mouse, as power bank | |
| Cable test | TDR cable test: BNC cable, network cable, telephone cable, RVV cable and elevator cable, cat 5/6 cable’s length and short circuit. Measurement range 1.2KM |
| Digital cable tracer:Search BNC cable, network cable and telephone cable from the mess cables, more accurately | |
| Support AC voltage detector: voltage range: AC12V-1000V, Frequency: 50/60Hz, Alarm mode: sound and light double alarm, Safety class: CAT.III 1000V / CAT.IV 600V;CE | |
| UTP cable test:UTP cable tester for connection status display. On-screen readout for near-end, mid-span, and far-end fault detection of RJ45 plugs. |
|
| RJ45 cable TDR test: Test cable pair status, length, attenuation, reflectivity, impedance, skew etc. measurement max range 180M.(590fts). | |
| Cable length test: Cable Tester for BNC, Ethernet, and Telephone Lines. Measures open-circuit faults up to 3KM (9842ft). Does not support short-circuit detection. | |
| Digital Multimeter (DMM) | Measures AC/DC voltage, current, resistance, capacitance. Supports data hold, relative mode, continuity test. Speed: 3 readings/sec. Range: ±6600. |
| Laser Distance meter | Measurement range80m, accuracy±3mm,Laser class 2,Laser type 635nm,Power output <1mW |
| Optical power meter (OPM) | Calibrated Wavelength(nm): 850/1300/1310/1490/1550/1625nm,Power range(dBm): -70～+10dBm |
| Visual fault locator (VFL) | Test fiber's bending and breakage |
| Built-in camera | Pixels: 8MP, support camera focus detection |
| TesterPlay | Screen projection: Tester, mobile phone and PC display at the same time (For android version mobile phone) |
| Audio test | 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
| Data monitor | Captures and analyzes the command data from controlling device, also can send hexadecimal |
| PSE/PoE test | Measurement PoE switch or PSE power supply voltage and cable connection status |
| Drop-down menu | You can select PoE power switch, IP setting, CVBS, LAN info, HDMI IN functions etc in any interface |
| CPU/RAM/EMMC | 2GHz 4-cores CPU 2GB RAM16GB FLASH(EMMC) |
| Battery | Built-in 7.4V Lithium polymer battery, 7800mAh, 57Wh |
| Rechargeable | After fast charging 3.5 hours, normal working time 11 hours(Without supplying power to other devices) |
| Dimension/Weight | 276mm x 163mm x 44mm / 1.14KG |
| Operating system | Android 11.0 |
